Mini PCI-E 88SE9215 4-Port SATA 6G Expansion Card SATA-3 Hard Disk Conversion Adapter Card

• Marvell 88SE9215 mini PCIe SATA3.0 expansion card with four SATA Gen III 6Gb/s channel host directors
• Provides server-level functionality for desktops. The motherboard supports the use of the industry's new, fast 6Gb/s hard disk drives, while providing backward compatible
• Traditional function SATA 1.5Gb/s, SATA 3Gb/s drive. It will enhance system performance for each type of computer user
• Each PCI Express 2.0 channel provides throughput of up to 500MB/S. SATA connected to this controller using RAID functionality
• The driver can be easily configured as 4 independent ports without RAID function

Specification:

• PCI Express：
• PCI Express 2.0 compliant, PCIe * 2.0 endpoint device
• Support 2.5 Gbps and 5.0 Gbps communication speed
• AHCI programming interface register supporting SATA controller
• Support integrated power management
• Support error reporting, recovery and correction
• Support message signal interrupt (MSI)
• SATA controller:
• Complies with Serial ATA specification 3.1
• Support 6 Gbps, 3 Gbps and 1.5 Gbps communication speed
• Support programmable transmitter signal level
• Support Gen 1i, Gen 1x, Gen 2i, Gen 2m, Gen 2x and Gen 3i
• Supports four SATA ports
• Support AHCI 1.0 programming interface
• Support for Native Command Queuing (NCQ)
• Support port based FIS switching or command based switching
• Support partial and sleep power management status
• Support interlaced rotation
• Operating system: Windows XP/Vista/Win 7/Win 8/Server 2003/Server 2008 R2, for Linux 2.6. x and higher, a computer with an available PCI Express slot
• Product size: 30*51mm (measured without Mini PCIe bracket)

Package included:

• 1 x Mini PCIe 88SE9215 SATA Expansion Card

• 1 x SATA Cable

• 1 x CD

• 1 x English User Manual

• Other things not included
